Thermo-hygrometer for compressed air measurement
Thermometer, hygrometer is designed for direct measurement of temperature, relative humidity for compressed air up to 25 bars with 1m cable. Audio and optical alarm of measured values. Memory of minimum and maximum measured values. Function Hold - manual storing of actual values for later displaying.
Simultaneous reading of temperature and relative humidity, dew point temperature reading selectable, external temperature-humidity probe with 1meter cable. Cable lengths 2 and 4 meters available optionally.
-
codeC3121P
-
Warranty3 years
Product variants
Technical data
Measured value
Temperature
Relative humidity
Counted values (dew point…)
TEMPERATURE SENSOR
Measuring range
-30 to +105 °C
Accuracy
±0.4 °C
Resolution
0.1 °C
HUMIDITY SENSOR
Measuring range
0 to 100 % RH
Accuracy
±2.5 % RH from 5 to 95 % at 23 °C
Resolution
0.1% RH
DEW POINT
Measuring range
-50 to +80 °C
Accuracy
±1.5 °C at ambient temperature T <25 °C and RH >30 %
Resolution
0.1 °C
GENERAL TECHNICAL DATA
Operating temperature
electronics -10 to +60 °C, external probe -30 to +105 °C
Channels
1x connectable temperature+humidity probe
Acoustic signalization + backlit LCD
YES
Measuring interval and display reading refresh
0.7 to 5 s
Power
battery 9 V or 12 Vss adaptor with NiMH 9 V battery
Battery life
approx. 4 months
Protection class
IP20 electronics, IP40 sensors
Dimensions (without connectors)
141 x 71 x 27 mm
External probe cable length
1 meter
Weight (including batteries)
approx. 150 g
Warranty
3 years
Optional accessories and download
ac/dc adapter 230Vac to 12Vdc/1A, EU
code
A1515eu
ac/dc adapter 230Vac to 12Vdc/1A, UK
code
A1515uk
ac/dc adapter 230Vac to 12Vdc/1A, US
code
A1515us
NiMH rechargeable batt. 9V/200mAh
code
A3400
Accredited temperature and relative humidity calibration
code
SLU003
sintered bronze sensor protection
code
F0000
plastic sensor protection with stainless filter (black)
code
F5200B
PTFE sensor protection, white
code
F5300
Humidity Standard 10%RH, set 5pcs
code
HM023
Humidity Standard 80%RH, set 5pcs
code
HM024
Vessel for adjustment and calibration of humidity
code
MD046
PP4 Flat circular flange
code
PP4
PP90 Right-angled stainless steel flange
code
PP90
Flow chamber for compressed air measurement up to 25 bars
code
SH-PP
COMET Magnetic Foldable Stand
code
PPO001
Software
Conversions - application for recalculation of values
Others
Terms and Conditions COMET System s.r.o.
Manuals
Instruction Manual
Quick Start Manual
Declaration of Conformity
Catalogs
CATALOG - Portable measuring instruments COMMETER
Catalogue Sheets - COMETTER
