Thermo-hygrometer for compressed air measurement
Thermometer, hygrometer is designed for measurement and datalogging of temperature, relative humidity for compressed air up to 25 bars with 1m cable into the internal non-volatile memory.
Free PC program enables to transfer recorded data to the computer for evaluation. LCD backlight.
Data logger is connected to the PC through USB cable only for data trasfer from the memory. During connection with the PC no measurement and record is enabled.
Simultaneous reading of temperature and relative humidity, dew point temperature reading selectable, external temperature-humidity probe with 1meter cable. Cable lengths 2 and 4 meters available optionally. Probe diameter is 18mm, length 135mm.
-
codeD3121P
-
Warranty3 years
Product variants
Technical data
Measured value
Temperature
Relative humidity
TEMPERATURE SENSOR
Measuring range
-30 to +105 °C
Accuracy
±0.4 °C
Resolution
0.1 °C
HUMIDITY SENSOR
Measuring range
0 to 100 % RH
Accuracy
±2.5 % RH from 5 to 95 % at 23 °C
Resolution
0.1% RH
DEW POINT
Measuring range
-50 to +80 °C
Accuracy
±1.5 °C at ambient temperature T <25 °C and RH >30 %
Resolution
0.1 °C
GENERAL TECHNICAL DATA
Operating temperature
electronics -10 to +60 °C, external probe -30 to +105 °C
Channels
1x connectable temperature+humidity probe
Acoustic signalization + backlit LCD
YES
Memory
16,000 values (non-cyclic record)
Recording interval
adjustable from 10 s to 24 h
Measuring interval and display reading refresh
0.7 to 5 s
Recording mode
noncyclic - data logging stops after filling the memory
cyclic - after filling memory oldest data is overwritten by new
cyclic - after filling memory oldest data is overwritten by new
Real time clock
year, leap year, month, day, hour, minute, second
Power
battery 9 V or 12 Vss adaptor with NiMH 9 V battery
Battery life
approx. 6 months
Protection class
IP20 electronics, IP40 sensors
Dimensions (without connectors)
191 x 71 x 27 mm; length/diameter of external probe 135/18 mm
External probe cable length
1 meter
Weight (including batteries)
approx. 150 g
Warranty
3 years
Optional accessories and download
ac/dc adapter 230Vac to 12Vdc/1A, EU
code
A1515eu
ac/dc adapter 230Vac to 12Vdc/1A, UK
code
A1515uk
ac/dc adapter 230Vac to 12Vdc/1A, US
code
A1515us
NiMH rechargeable batt. 9V/200mAh
code
A3400
Accredited temperature and relative humidity calibration
code
SLU003
Transducer USB/RS232 complete
code
MP006
Mini USB cable, 2 meters
code
MP038
Communication cable for COMMETER Dxxxx
code
QLOG015
Mini USB cable, 2 meters
code
MP038
sintered bronze sensor protection
code
F0000
plastic sensor protection with stainless filter (black)
code
F5200B
PTFE sensor protection, white
code
F5300
Humidity Standard 10%RH, set 5pcs
code
HM023
Humidity Standard 80%RH, set 5pcs
code
HM024
Vessel for adjustment and calibration of humidity
code
MD046
PP4 Flat circular flange
code
PP4
PP90 Right-angled stainless steel flange
code
PP90
Flow chamber for compressed air measurement up to 25 bars
code
SH-PP
COMET Magnetic Foldable Stand
code
PPO001
